command is completed (CMDOK), and then the
internal position command triggered by the DI
signal command trigger (CTRG) is accepted.
F4-2
The setting of
position
cycle
numbers for
internal
position
command 1
Sets the number of position turns for the internal
position of the first segment.
-30000-
30000
0
F4-3
The setting of
pulse number
in position
cycle for
internal
position
command 1
1. To set position pulses of the first internal position.
2. Internal position command=the setting value of
the first internal position cycles+the setting value of
the first internal position pulses.
(Max is the pulse number of the motor rotation for
each roll, please refer to the settings of FA11,FA12
and FA13 ).
+/-max.
cnt/rev
0
F4-4
The move
speed of
Internal
position
instruction 1
To set the move speed of internal position instruction 1.
0-5000
r/min
1000
F4-5
The number
of position
cycles of
internal
position
instruction 2
To set the number of position cycles of the second
stage internal position.
-30000-
30000
0
F4-6
The pulse
number
setting in
position loop
of internal
1. To set the position pulses of the second stage
internal position.
2. Internal position instruction 2=the position
cycles setting of the second internal position+the
pulse number setting of the second internal position.
+/-max.
cnt/rev
0
