3BN/3A4
2-3-3
Terminals (CN) Voltage Remarks
1-2 1-7 0/5 V DC PCM control signal (MODE), input
1-3 1-9 5/0 V DC TOCSW on/off, output
1-4 1-7 0/5 V DC PCM on/off, input
1-5 1-7 0/5 V DC PCM control signal CWB, input
1-6 1-7 0/5 V DC (pulse) PCM clock signal, input
1-8 1-7 5 V DC 5 V DC supply, input
2-1 2-3 0/5 V DC RESET signal, input
2-4 2-5 0/5 V DC (pulse) Serial signal TXD, input
2-6 2-7 0/5 V DC (pulse) Serial signal RXD, output
2-8 2-7 5 V DC 5 V DC supply, input
2-11 2-9 24 V DC 24 V DC supply, input
2-12 2-10 24 V DC 24 V DC supply, input
3-1 3-4 0/24 V DC SBSOL release signal, input
3-2 3-4 0/24 V DC SBSOL latch-on signal, input
3-3 3-4 24 V DC 24 V DC supply for SBSOL, input
3-5 3-4 0/5 V DC PCSW on/off, output
3-6 3-4 5 V DC 5 V DC supply for PCSW, input
3-7 3-4 0/24 V DC FSSOL release signal, input
3-8 3-4 0/24 V DC FSSOL latch-on signal, input
3-9 3-4 24 V DC 24 V DC supply for FSSOL, input
4-1 4-29 24 V DC 24 V DC supply for FSSOL, output
4-2 4-29 0/24 V DC FSSOL latch-on signal, output
4-3 4-29 24 V DC 24 V DC supply for SBSOL, output
4-4 4-29 0/24 V DC FSSOL release signal, output
4-5 4-29 24 V DC 24 V DC supply for PUSOL, output
4-6 4-29 0/24 V DC SBSOL latch-on signal, output
4-7 4-29 0/24 V DC PUSOL on/off, output
4-8 4-29 0/24 V DC SBSOL release signal, output
4-9 4-29 5 V DC 5 V DC supply for PCSW, output
4-10 4-29 0/5 V DC PCSW on/off, input
4-11 4-23 5 V DC 5 V DC supply for SRFHPS, output
4-12 4-23 0/5 V DC SRFHPS on/off, input
4-13 4-25 5 V DC 5 V DC supply for SRRHPS, output
4-14 4-25 0/5 V DC SRRHPS on/off, input
4-15 4-27 5 V DC 5 V DC supply for stapler, output
4-16 4-27 0/5 V DC STHPS on/off, input
4-17 4-21 5 V DC 5 V DC supply for ITS, output
4-18 4-21 0/5 V DC ITS on/off, input
4-19 4-28 5 V DC 5 V DC supply for TERHPS, output
4-20 4-27 0/5 V DC STCS on/off, input
4-22 4-27 0/5 V DC STES on/off, input
4-24 4-27 0/5 V DC STSPS on/off, input
4-26 4-28 0/5 V DC TERHPS on/off, input
5-1 3-4 0/24 V DC (pulse) FSRM motor coil energization pulse, output (A)
5-2 3-4 24 V DC 24 V DC supply for FSRM, output
5-3 3-4 0/24 V DC (pulse) FSRM motor coil energization pulse, output (B)
5-4 3-4 0/24 V DC (pulse) FSRM motor coil energization pulse, output (B)
5-5 3-4 0/24 V DC (pulse) FSRM motor coil energization pulse, output (A)
5-6 3-4 0/24 V DC (pulse) RSRM motor coil energization pulse, output (A)
5-7 3-4 24 V DC 24 V DC supply for RSRM, output
5-8 3-4 0/24 V DC (pulse) RSRM motor coil energization pulse, output (B)
5-9 3-4 0/24 V DC (pulse) RSRM motor coil energization pulse, output (B)
5-10 3-4 0/24 V DC (pulse) RSRM motor coil energization pulse, output (A)
6-1 3-4 0/24 V DC (pulse) TERM motor coil energization pulse, output (A)
6-2 3-4 0/24 V DC (pulse) TERM motor coil energization pulse, output (B)
6-3 3-4 0/24 V DC (pulse) TERM motor coil energization pulse, output (B)
