3BN/3A4
2-3-4
Terminals (CN) Voltage Remarks
6-4 3-4 0/24 V DC (pulse) TERM motor coil energization pulse, output (A)
6-5 3-4 24 V DC 24 V DC supply for TERM, output
6-7 3-4 24 V DC 24 V DC supply for PCM, output
6-8 3-4 24 V DC 24 V DC supply for PCM, output
6-9 3-4 0/24 V DC (pulse) PCM motor coil energization pulse, output (A)
6-10 3-4 0/24 V DC (pulse) PCM motor coil energization pulse, output (A)
6-11 3-4 0/24 V DC (pulse) PCM motor coil energization pulse, output (B)
6-12 3-4 0/24 V DC (pulse) PCM motor coil energization pulse, output (B)
6-13 3-4 0/24 V DC STM forward rotation drive signal (F), output
6-14 3-4 0/24 V DC STM forward rotation drive signal (F), output
6-15 3-4 0/24 V DC STM reverse rotation drive signal (R), output
6-16 3-4 0/24 V DC STM reverse rotation drive signal (R), output
7-3 3-4 24/0 V DC TOCSW on/off, input
7-6 3-4 24/0 V DC LCSW on/off, output
7-7 3-4 24 V DC 24 V DC supply for LCSW, output
7-8 3-4 24/0 V DC LCSW on/off, input
