Copystar CS-3035 - Page 314

2FD/2FF/2FG
2-3-10
Connector Pin No. Signal I/O Voltage Description
YC9
Connected
to the
BYPFSW,
TCS, TNS,
developing
unit,
TNFSOL,
TCDSW
and drum
unit.
YC10
Connected
to the RSW,
fixing unit,
DUPFCL,
DUPPCSW
and CFM 5
to 7.
YC11
Connected
to the DM,
PFM, FCL1
and FSW1.
A1 GND - - Ground
A2 BYPFSW I 0/5 V DC BYPFSW ON/OFF
A3 5V O 5 V DC 5 V DC supply for BYPFSW
A4 5V O 5 V DC 5 V DC supply for TCS
A5 TCS I 0/5 V DC TCS ON/OFF
A6 GND - - Ground
A7 PO - - Ground
A8 5V O 5 V DC 5 V DC supply for TNS
A9 TNS I 0/5 V DC TNS ON/OFF
A10 GND - - Ground
A11 DVUNITN I 0/5 V DC Developing unit detection signal
A12
FUSE CUT REM O 0/5 V DC Developing unit FUSE CUT signal
A13 N.C - - Not used
B1 GND - - Ground
B2 TNFSOL O 0/24 V DC TNFSOL ON/OFF
B3 TCDSW I 0/5 V DC TCDSW ON/OFF
B4 GND - - Ground
B5 PO - - Ground
B6 GND - - Ground
B7 CL O 0/5 V DC CL ON/OFF
B8 EEDATA O 0/5 V DC Drum unit DATA signal
B9 EESCLK O 0/5 V DC Drum unit CLOCK signal
B10 GND - - Ground
B11 DRUNITN I 0/5 V DC Drum unit detection signal
B12 5V O 5 V DC 5 V DC supply for drum unit
B13 N.C - - Not used
A1 GND - - Ground
A2 RSW I 0/5 V DC RSW ON/OFF
A3 5V O 5 V DC 5 V DC supply for RSW
A4 PO - - Ground
A5 5V I 5 V DC 5 V DC supply from FTH1
A6 FTH1 I 0 to 5 V DC FTH1 detection voltage
A7
FUSE CUT REM I 0/5 V DC FTH1 detection voltage
A8 GND - - Ground
A9 5V I 5 V DC 5 V DC supply from FTH2
A10 FTH2 I 0 to 5 V DC FTH2 detection voltage
B1 24V O 24 V DC 24 V DC supply for DUPFCL
B2 DUPFCL O 0/24 V DC DUPFCL ON/OFF
B3 GND - - Ground
B4 DUPPCSW I 0/5 V DC DUPPCSW ON/OFF
B5 5V I 5 V DC 5 V DC supply from DUPPCSW
B6 GND - - Ground
B7 SET SIG I 0/5 V DC Duplex section connection signal
B8 DUP PO - - Ground
B9 R24V O 24 V DC 24 V DC supply for CFM5 to 7
B10 CFM5,6,7 O 0/24 V DC CFM5 to 7 ON/OFF
1 R24V O 24 V DC 24 V DC supply for DM
3 PG - - Ground
5 5V O 5 V DC 5 V DC supply for DM
7 SG - - Ground
9 DM S/S O 0/24 V DC DM S/S signal
11 DM L/D I 0/24 V DC DM L/D signal
13 DM CLK O 0/5 V DC (pulse) DM CLOCK signal
2 R24V O 24 V DC 24 V DC supply for PFM
4 PG - - Ground
6 5V O 5 V DC 5 V DC supply for PFM
8 SG - - Ground
10 PFM S/S O 0/24 V DC PFM S/S signal
12 PFM L/D I 0/24 V DC PFM L/D signal
14 FCL1 O 0/24 V DC FCL1 ON/OFF
