2FD/2FF/2FG
2-3-11
Connector Pin No. Signal I/O Voltage Description
YC11
Connected
to the DM,
PFM, FCL1
and FSW1.
YC12
Connected
to the upper
and lower
paper size
length
switches.
YC13
Connected
to the
FSW2,
FSW3,
FCL2,
FCL3,
SCSW, LM-
U, LM-L,
PLSW-U,
PLSW-L,
LICSW-U,
LICSW-L,
PPSW-U
and PPSW-
L.
15 24V O 24 V DC 24 V DC supply for FCL1
16 GND - - Ground
17 FSW1 I 0/5 V DC FSW1 ON/OFF
18 5V O 5 V DC 5 V DC supply for FSW1
1 R24V O 24 V DC 24 V DC supply for PWSW-U
2 UP24V I 24 V DC 24 V DC supply from PWSW-U
3 PWSW-U0 I 0/24 V DC PWSW-U paper width detection signal
4 PWSW-U1 I 0/24 V DC PWSW-U paper width detection signal
5 PWSW-U2 I 0/24 V DC PWSW-U paper width detection signal
6 GND - - Ground
7 R24V O 24 V DC 24 V DC supply for PWSW-L
8 LO24V I 24 V DC 24 V DC supply from PWSW-L
9 PWSW-L0 I 0/24 V DC PWSW-L paper width detection signal
10 PWSW-L1 I 0/24 V DC PWSW-L paper width detection signal
11 PWSW-L2 I 0/24 V DC PWSW-L paper width detection signal
12 GND - - Ground
A1 GND - - Ground
A2 FSW3 I 0/5 V DC FSW3 ON/OFF
A3 5V O 5 V DC 5 V DC supply for FSW3
A4 24V O 24 V DC 24 V DC supply for FCL3
A5 FCL3 O 0/24 V DC FCL3 ON/OFF
A6 GND - - Ground
A7 FSW2 I 0/5 V DC FSW2 ON/OFF
A8 5V O 5 V DC 5 V DC supply for FSW2
A9 GND - - Ground
A10 SCSW I 0/5 V DC SCSW ON/OFF
A11 24V O 24 V DC 24 V DC supply for FCL2
A12 FCL2 O 0/24 V DC FCL2 ON/OFF
A13 LM-U SW2 I 0/5 V DC LM-U paper level detection switch ON/OFF
A14 GND - - Ground
A15 LM-U SW1 I 0/5 V DC LM-U paper level detection switch ON/OFF
A16 GND - - Ground
A17 LM-U REM O 0/24 V DC LM-U ON/OFF
A18 GND - - Ground
A19 PLSW-L I 0/5 V DC PLSW-L ON/OFF
B1 GND - - Ground
B2 PLSW-U I 0/5 V DC PLSW-U ON/OFF
B3 LM-L SW2 I 0/5 V DC LM-L paper level detection switch ON/OFF
B4 GND - - Ground
B5 LM-L SW1 I 0/5 V DC LM-L paper level detection switch ON/OFF
B6 GND - - Ground
B7 LM-L REM O 0/24 V DC LM-L ON/OFF
B8 GND - - Ground
B9 LICSW-U I 0/5 V DC LICSW-U ON/OFF
B10 5V O 5 V DC 5 V DC supply for LICSW-U
B11 GND - - Ground
B12 PPSW-U I 0/5 V DC PPSW-U ON/OFF
B13 5V O 5 V DC 5 V DC supply for PPSW-U
B14 GND - - Ground
B15 LICSW-L I 0/5 V DC LICSW-L ON/OFF
B16 5V O 5 V DC 5 V DC supply for LICSW-L
B17 GND - - Ground
B18 PPSW-L I 0/5 V DC PPSW-L ON/OFF
B19 5V O 5 V DC 5 V DC supply for PPSW-L
