TigoMaster 2TH – PROFINET User Manual

Page 47 of 69

No.

Name

Value Range

Default

Description

Unique ID

– Byte 10

0 … 255

Unique ID of the W-Device. See example in

section 5.6.3.1.

5.6.3.1. Unique ID Parameters: Example

If the unique ID of the W-Device is 03:F3:00:00:01:30:C0:45:CF, then the Unique ID parameters are set

as follows:

• Byte 1 = CF

• Byte 2 = 45

• Byte 3 = C0

• Byte 4 = 30

• Byte 5 = 01

• Byte 6 = 00

• Byte 7 = 00

• Byte 8 = F3

• Byte 9 = 03

Table of Contents2
Introduction7
About7
Typographical Conventions7
Symbols7
Deviating Views7
Safety and Requirements8
General Note8
Intended Use8
Personnel Qualification8
Power Drop for Write/Delete Access in File System8
Exceeding the Max. No. of Permitted Write/Delete Access9
Information and Data Security9
Regulatory Notices9
Class a Warnings - Industrial Use9
FCC Warning9
ISED Warning9
Interference Statement10
Wireless Notice10
Requirements10
Hardware and System Requirements10
Software Requirements11
Getting Started12
Description12
Overview12
Functionality12
Figure 1: Tigomaster 2TH (PROFINET Version)12
Table 1: Tigomaster 2TH Functionality (PROFINET Version)13
Lasering14
Revisions and Versions14
Table 2: Tigomaster 2TH Hardware14
Table 3: Tigomaster 2TH Software14
Table 4: Tigomaster 2TH Firmware14
Identification15
LED Indications15
Figure 2: Tigomaster 2TH Identification Code15
Table 5: System Leds15
Table 6: System LED States15
Table 7: APL Leds16
Table 8: Supply Voltage Leds16
Table 9: PROFINET IO-Device Status16
Table 10: LED States PROFINET IO17
Table 11: Ethernet Status17
Table 12: Ethernet LED States17
Table 13: Wireless Track Status WT117
Connectors and Interfaces18
Table 14: Wireless Track Status WP0118
Table 15: Power Supply Connectors18
Table 16: Ethernet Connectors19
Table 17: SMA Antenna19
Installation20
The Mounting Process20
Mounting20
Grounding (Optional)22
Demounting22
Connections and Booting23
Figure 3: Connection24
Configuration and Commissioning25
Table 18: Configuration Tools25
Setting IP with the PROFINET IO-Controller26
Prerequisites26
Connecting to the PLC26
Figure 4: Manage GSD Files26
Figure 5: Manage General Station Description Files - Installed Gsds Tab27
Figure 6: List of Available GSD Files27
Figure 7 - New Module Added to Hardware Catalog28
Figure 8: Network View28
Figure 9: Device View29
Figure 10: Ethernet Addresses30
Configuring Submodules31
Figure 11: Device Overview31
Figure 12: Device Inspector Window31
Figure 13: Module Parameters32
Figure 14: Unique ID32
Figure 15: Show All Tags33
Figure 16: Tags Tab33
Port Submodule Parameters34
Figure 17: Watch Table34
Table 19: Port Submodule Parameters34
Configuring Tigomaster 2TH with Tigoengine35
Masters View35
Connecting a New Tigomaster 2TH35
Figure 18: Connect New Master Button36
Figure 19: Connect Button36
Tigoengine Connection Types37
Configuring Parameters37
Figure 20: Masters View - One Tigomaster 2TH Connected37
Configuring Tigomaster 2TH with the Integrated Web Server (Netfield)38
Opening the Integrated Web Server38
Figure 21: Integrated Web Server Dashboard38
Table 20: Dashboard Information38
Overview of Configuration Tab and Scan Settings Tab39
Tigomaster 2TH Advanced Configuration View39
Setting the Tigomaster 2TH IP Address Using a DHCP Server39
Table 21: Tigomaster 2TH Advanced Configuration View39
Installing and Using Open DHCP Server40
Setting the IP Address with the Ethernet Device Configuration Software40
Figure 22: List of Devices Found in Local Network41
Figure 23: IP Configuration Dialog Box41
Parameters42
Port Cycle Time42
I-Am-Alive Time42
Table 22: Port Cycle Time Calculation42
Table 23: Time Base of I-Am-Alive Time43
Table 24: Calculation of I-Am-Alive Time43
Parameters to be Set for Connection 144
Table 25: Parameters 10 to 8544
Table 26: Parameter 9045
Table 27: Parameters 410 to 45646
OPC UA Server Connection48
Tigomaster 2TH48
Identification48
Figure 24: Path to Tigomaster 2TH Device Identification Nodes48
Sensor/Actuator Identification49
Wireless Connection49
Table 28: Device Identification Nodes49
Table 29: Sensor/Actuator Identification Nodes49
Table 30: Track and Slot (Double-Slot)50
Table 31: Track and Slot (Single-Slot)50
Status and Diagnosis51
Tigomaster 2TH51
Profinet51
Instance 0 (Class Attributes)51
Instances 100, 10151
Table 32: Class Attributes Event Log Object 65 (0X41)51
Table 33: Mapping CIP Instances to IO-Link Ports51
Table 34: Instance Attributes Event Log Object 65 (0X41)52
Attribute 14: Structure of a Log Entry53
Services53
Table 35: Log Entry Structure53
Table 36: Services Event Log Object 65 (0X41)53
IO-Link54
Event Qualifier54
IO-Link Wireless Master Event Codes54
Figure 25: Event Qualifier54
Table 37: Event Qualifier54
Table 38: Master Event Codes54
IO-Link Device Event Codes (Common)55
Table 39: Device Event Codes55
Technical Data58
Product Specifications58
Table 40: Product Specifications58
Protocol Specifications61
Table 41: Protocol Specifications61
Dimensions63
Figure 26: Dimensions63
Appendix A - Part Number64
Appendix B - Evaluation Agreement65
