Artiglio Master Code User Manual 39
UK
a. press the button (Fig. 30c) and then press the
icon (Fig. 30a) again and repeat automatic
wheel data acquisition.
b. manually store wheel data:
- use the arrows (Fig. 30c) to set the rim
diameter.
N.B.: The large arrows increase or decrease the size by one inch, at each pressure step: The
small arrows increase or decrease the size by one tenth of an inch each time they are pressed.
- Operate the control on the push-button panel to
position the tool on the wheel as shown in Fig. 30d.
N.B.: To obtain a more precise position, press the button at
the top of the control (see Fig. 30e).
- Act on the bottom bead breaker command
to position it as illustrated in Fig. 30f.
- Press the camera button (optional) to facilitate
positioning of the bottom bead breaker disc
.
- Press the key (Fig. 30c) to store the wheel dimensions.
Once saving is completed the tool and the bead breakers will make a small move-
ment away from the wheel.
NOTICE
30d
30e
30f
30c
