Corghi Artiglio Master Code - Page 60

60 Artiglio Master Code User Manual
Take care to avoid any injuries. Ensure that the top bead is correctly loaded on the tool
before carrying out mounting (Fig. 37h).
- Press the pedal to start rotation until the second bead has been mounted.
Take care to avoid any injuries. Make sure the top bead is correctly inserted in the rim
well, throughout the mounting stage.
WARNING
- Remove the bead pressing pliers or the bead pressing tool.
At the end of the operation the machine will return to the main screen or will launch the
INFLATRON (optional), if active.
NOTICE
Position the bead pressing tool in the correct rest
position (Fig. 37i) so that it does not interfere
with the work area.
WARNING
- Take the bead breaker back to the top and bottom extremity (Fig. 37l).
- Withdraw the fixed tool
from the work area (Fig. 37m).
I
WARNING
37i
