Artiglio Master Code User Manual 59
UK
Maintain a light manual pressure on the tyre section with the lower bead not yet
inserted in the rim.
NOTICE
After mounting the first bead the machine
positions the fixed tool and the top bead
breaker on the upper part of the tyre in
the correct top bead mounting position.
(Fig. 32e).
NOTICE
The top bead breaker automatically hooks during the descent phase.
5 - Act on the lever lowering the tool and
manually adjusting the tyre into position (Fig. 37f).
6 - Push the tyre
under the shoulder level
(Fig. 37g).
7 - Use the bead pressing tool (Fig. 37g) and, if
necessary, bead pressing pliers (Fig. 37h) on the rim
shoulder, ensuring that the top bead is in the channel.
37e
37f
A
37h37g
WARNING
