Corghi Artiglio Master Code - Page 63

Artiglio Master Code User Manual 63
UK
well, otherwise use the bead depressor to facilitate
positioning (Fig. 40g).
8- Turn the selector (see Fig. 40h).
9- Keeping the selector turned , press the
Pedal
to rotate the turntable and demount
the upper part of the tyre from the rim.
If necessary, operate the control
to slightly raise
the head and complete upper bead removal.
10- Release the Selector
and the Pedal
11- Move the movable tool away from the work area
.
12- Operate
to move the head in the lower part
of the wheel (Fig. 40i).
13- Manually position the tyre so that the tool hook is
between the lower bead and the rim (Fig. 40l).
14- Operate the lever
to position the fixed tool at
the correct height for removing the second bead (Fig. 40m).
40g
40h
40i
40l
40m
