66 Artiglio Master Code User Manual
10- Use the bead presser (Fig. 41f) and, if necessary, the bead presser gripper(s) (Fig. 41g),
on the shoulder of the rim, to make sure the upper bead stays in the rim well.
Avoid personal injury. Make sure the upper bead is correctly loaded on the tool be-
fore mounting (Fig. 41g).
11- Press the pedal
to start rotation, until the second bead has been assembled.
Avoid personal injury. Make sure the upper bead is correctly inserted in the rim well,
throughout the mounting stage.
WARNING
12- Remove the bead presser gripper(s) or bead presser.
13- Return the bead breakers to the top
and bottom ends (Fig. 41h).
41g
41f
WARNING
41h
