PBD175 (Spire 3.0)) Service Manual
© 2015-2016, Cornelius Inc. - 15 - Publication Number: 620062609SER
Figure 18.
NUC Power Button
To shut down the computer using the computer power button, perform the procedure in Table 3.
Table 3.
Step Action
1
Open the unit door.
2
To shut down the computer, press and release the exposed NUC power button, as shown in Figure 19. This
operation provides the same function as a software shutdown.
Holding the NUC power button for 5 seconds is an unsafe, hard shutdown. This is not advised during normal
operation
.
3
To reboot the computer, pres the NUC power button for 1 second. The blue light illuminates and the display
goes through the boot up routine. At the end of the routine, the main user screen is displayed. Wait 15 sec-
onds after the main user screen is displayed for communications to be completed to the Valve Control
board.
