PBD175 (Spire 3.0) Service Manual
Publication Number: 620062609SER - 22 - ©2015-2016, Cornelius Inc.
System
This selection monitors vital temperatures of the computer. These include the CPU & SSD temperatures and fan
speed. If the icon is red check the system fans to make sure they are operating.
Valve Controller
Validates communication between the computer and valve board.
ADA Controller
Validates communication between the computer and ADA board.
Touch Controller
Validates communication between the computer and display.
PREVENTATIVE MAINTENANCE
This selection is a reminder to the technician that a designated amount of time has expired and these systems
should be checked. The display is shown in Figure 31. If they are highlighted RED the technician should check the
component highlighted and clear the alarm when completed. They include:
• Water Filter
• Lines & Valve Sanitation
• Power Supply Fan Clean
• Computer Fan Clean
Figure 31.
