4-SHIPPING, HANDLING AND UNPACKING 4-3
COROB™ TATOCOLOR
Make sure the machine has not been damaged during shipping; if so, do not attempt to
start it. Contact the authorized technical service or dealer immediately.
Inside the packing you will find the material supplied:
 power supply cable
 computer/machine RS232 serial communication cable
 computer power cables
 a kit of spare fuses
 panel key and screwdriver
 sponges and, if necessary, spare holding lid for the humidifier cap
 user's manual
 CE declaration of conformity and installation and warranty start form
 equipment software tools standard CD
Depending on the machine model and/or the options specified on the purchase order, you may
also find:
 management program with corresponding user's manual and protection key
 device for screwing/unscrewing punch tool with a manual plugger
Make sure that all of the above items are included in the packing; if not, contact the
manufacturer.
The machine is firmly attached to the pallet by means of two fastening brackets.
At least 3 people must work together to remove the machine from the pallet.
To remove the machine from the pallet, lower it to the ground and place it correctly on the
installation site, follow the procedure below carefully:
1. Lower both platforms (1) hinged to the pallet, making sure they rest evenly on the floor and
that they are well aligned with the pallet surface (Figure 4-2).
Figure 4-2
2. Slightly loosen the two screws (1) that fix the front bracket to the base of the pallet (Figure
4-3).
3. Remove the side panels of the canister sections.
