Calibration Calibrating the Scale
CubiScan 125 45
Calibrating the Scale
To perform the calibration, you will need the following:
• Official test weight up to 50 pounds (25 kg) (it is recommended that you
calibrate with the maximum weight)
IMPORTANT: Do not begin scale calibration until you have the test
weight. Calibrating without an accurate known weight (within .01 of a
lb/kg) can make all future weight readings inaccurate.
Take the following steps to calibrate the CubiScan 125 scale.
NOTE
When calibrating the scale, the CubiScan 125 must be stable with no movement of
the platform such as that caused by vibration or air movement.
1. At the home screen, tap MENU.
NOTE
If you have set up a password previously in the system configuration, you need to
enter the password to unlock the menu. Refer to page 32.
Figure 39
Home Screen
