CubiScan 125 5
Chapter 2
Setup
This chapter provides instructions for assembling and setting up the
CubiScan 125. Perform the steps to set up the CubiScan 125 in the following
order:
• Unpacking (page 5)
• Placement (page 6)
• Assembly (page 7)
• Attaching top sensor support (page 8)
• Routing height sensor cable (page 9)
• Removing the shipping material (page 12)
• Placing the glass platform (page 13)
• Connecting power (page 14)
• Turning the CubiScan 125 on (page 14)
• Connecting to a computer or network (optional) (page 15)
• Installing the Qbit software (optional) (page 21)
Unpacking
The CubiScan 125 is shipped in a single container with all components. The
glass platform is packed in a separate cardboard box inside the crate.
Remove the wood slats and the packing material, and lift the CubiScan 125
components carefully from the crate. Do not remove the green foam
shipping supports between the scale base and platform or the wire tie that
holds the measuring gate in place; they will help prevent damage to the
load cells and gate while you are assembling the CubiScan 125.
