Curtis 1226 User Manual

8 — DIAGNOSTIC AND TROUBLESHOOTING
pg. 83
Return to TOC Curtis Model 1226 – September 2019
Table 33 Faults, cont’d
Code Fault and Fault Action Possible Causes Set and Clear Conditions
10,4
Analog 1 Out of Range
No fault action
• The analog input’s voltage is above the
voltage specied by the High parameter.
• The analog input’s voltage is below the
voltage specied by the Low parameter.
Set: The input voltage is not within
the range of voltages dened
by the input’s High and Low
parameters.
Clear: Either return the voltage
to within the congured range or
recongure the parameters, then
cycle the keyswitch.
10,5
Analog 2 Out of Range
No fault action
10,6
Analog 3 Out of Range
No fault action
10,7
Analog 4 Out of Range
No fault action
10,8
Analog 5 Out of Range
No fault action
10,9
Analog 6 Out of Range
No fault action
10,10
Analog Assignment
No fault action
An analog input is being used for two or more
functions.
Set: The controller detected an
analog assignment conict.
Clear: Resolve the conict, then
cycle the keyswitch.
11,4
EMR SRO
ShutdownThrottle
The emergency reverse switch was on when
the keyswitch was powered on.
Set: The operator turned the
keyswitch on while the emergency
reverse switch was on.
Clear: Turn off the emergency
reverse switch, then cycle the
keyswitch.
11,5
Load Hold SRO
ShutdownDriver
The load hold switch was on when the
keyswitch was powered on.
Set: The operator turned the
keyswitch on while the load hold
switch was on.
Clear: Turn off the load hold
switch, then cycle the keyswitch.
11,6
Hydraulic SRO
ShutdownDriver
The hydraulic lift switch was on when the
keyswitch was powered on.
Set: The operator turned the
keyswitch on while the hydraulic
lift switch was on.
Clear: Turn off the hydraulic lift
switch, then cycle the keyswitch.
