Curtis 1226 User Manual

8 — DIAGNOSTIC AND TROUBLESHOOTING
Curtis Model 1226 – September 2019
Return to TOC
pg. 82
Table 33 Faults, cont’d
Code Fault and Fault Action Possible Causes Set and Clear Conditions
7,7
Supervision
ShutdownMotor
ShutdownMainContactor
ShutdownEMBrake
ShutdownThrottle
ShutdownInterlock
ShutdownDriver1
ShutdownDriver2
ShutdownDriver3
The controller failed.
Note: When a Supervision fault is active, the
Supervision Error eld displays a value that
provides information on the cause. See Table
29.
Set: Internal controller failure.
Clear: Cycle the keyswitch.
8,8
Internal Hardware
ShutdownMotor
ShutdownMainContactor
ShutdownEMBrake
ShutdownThrottle
An internal controller fault occurred Set: The controller detected an
internal fault.
Clear: Cycle the keyswitch.
8,10
Parameter Out Of Range
ShutdownMotor
ShutdownMainContactor
ShutdownEMBrake
ShutdownThrottle
A parameter is set to an invalid value. Set: The controller detects an
invalid parameter value.
Clear: Update the parameter to a
valid value.
9,4
Emer Rev Timeout
ShutdownThrottle
ShutdownEMBrake
• An emergency reverse operation ended
because the operation exceeded the EMR
Time Limit; see page 43.
• The emergency reverse input is stuck in
the on position.
Set: An emergency reverse
operation stopped when it reached
the specied time limit.
Clear: Turn off the emergency
reverse switch.
9,5
Parameter Mismatch
ShutdownMotor
ShutdownMainContactor
ShutdownEMBrake
ShutdownThrottle
ShutdownVehicle
Two or more parameters are set to conicting
values.
The Mismatch Error eld identies the cause.
See page 57.
Set: The controller detects
conicting parameter values.
Clear: Adjust the parameters, then
cycle the keyswitch.
9,9
Driver 1
ShutdownDriver1
• The coil is open or shorted.
• Dirty connector pins for the controller or
the contactor coil.
• Bad connector crimps or faulty wiring.
• Driver overcurrent
Set: The driver is open or shorted.
Clear: Address the possible
causes, then cycle the keyswitch.
9,10
Driver 2
ShutdownDriver2
10,1
Driver 3
ShutdownDriver3
10,3
Driver Assignment
ShutdownDriver{n}
A driver output is being used for two or more
functions.
Set: A driver assignment conict is
detected.
Clear: Resolve the driver conict,
then cycle the keyswitch.
