Mass Storage / FTP Server
It is possible to add the new logo directly into the folder “PICTURES” on the Flash Drive of the printer.
You can enter the Flash Drive by fi les sharing from Mass Storage or by fi les sharing from FTP Server connection
(see par. 12.1).
In both cases, the relative parameter should be enabled during the confi guration process (see chapter 5).
After adding the logo, open the confi guration fi le “PictList.ini” and add a new line with a number associated to the logo
(to be used with printer’s commands), a letter for the memory unit and the logo fi le name, as indicated in the instruc-
tions written inside the “PictList.ini” fi le.
To delete a logos stored in the printer, proceed as follows:
1. delete the selected logo from the “Pictures” folder on Flash Disk or SD/MMC card;
2. in the confi guration fi le “PictList.ini”, delete the line related to the erased logo.
The logos stored into a unit memory and converted by the printer, can be printed by using the number associated to
the logo during the conversion step.
The correspondence between fi le-name and logo-number is warrant by the confi guration fi le “PIctList.ini” and it is
verifi able with the logo test.
NOTE:
To know the IP address of the printer, print the Set-up report of the printer (see chapter 5) or use “Locator”. Type in
the address bar “ftp://” followed by the IP address of the printer.
ATTENTION:
The confi guration fi le “PictList.ini” on the printer’s Flash Disk, has to be modifi ed even if the new added
logo is stored on SD/MMC.
12. ADVANCED FUNCTIONS
104 KPM216HII ETH User manual
