12.2 Embedded Web Server
Printers are equipped with an Embedded Web Server that allows to execute some operations on printers, through a
clear web interface, including:
• monitoring the printer status;
• setting operating parameters;
• confi guring network settings;
• managing the logos;
• confi guring the email service to make diagnostics and maintenance operations easier;
• download printing drivers.
Before entering in the Embedded Web Server, check that:
• the printer is connected and turned on;
• the printer has a network connection based on the IP protocol;
• the following ports are opened (if a Firewall is present on computer): 9100 (or differently set up). 15000, 15001,
15002;
• have a Web browser on the computer;
• the printer is connected to the network and its IP address and its Subnet Mask are set up in a correct way. To
check the setting of these parameters, open a new terminal window and type “ping” on the command bar followed
by the IP address of the printer. The picture shows an example of a positive result after the “ping” command.
Otherwise, if connection isn’t possible, to its IP address, a failure notice will appear.
Example: ping 192. 168. 10. 37
Microsoft Windows XP [Version 5.1.2600]
(C) Copyright 1985-2001 Microsoft Corp.
C:\>ping 192.168.10.27
Pinging 192.168.10.37 with 32 bytes of data:
Replay from 192.168.10.37: bytes=32 time<1mx TTl=64
Replay from 192.168.10.37: bytes=32 time<1mx TTl=64
Replay from 192.168.10.37: bytes=32 time<1mx TTl=64
Replay from 192.168.10.37: bytes=32 time<1mx TTl=64
Ping statistics for 192.168.10.37:
Packets: sent = 4, Received = 4, Lost = 0 (0% loss.),
Approximate round trip times in milli-seconds:
minimum = 0ms, Maximum = 0ms, Avereage = 0ms
c:\>
Command Prompt
12. ADVANCED FUNCTIONS
96 KPM216HII ETH User manual
