4.4 Issuing ticket
The printer allows you to choose between different operating modes for the issuance of printed tickets.
The operating modes shown in the following images, depend on the settings of the confi guration parameters and
commands sent to the printer.
NOTE: For further information, refer to Chapter 5 and to the Commands Manual.
“PRESENT” MODE
1
The device starts the ticket printing
2
The ticket advances ahead to the ejector and is caught between the ejector rollers.
The printed part of ticket is collected while the device continues printing
Paper input Printing head
Printing head
Paper caught
between rollers
Ejector rollersPaper input
4. OPERATION
User manual KPM216HII ETH 31
