5.2 Setup report
The following fi gures show the setup reports of the printer. The shown values for parameters are sample values; for
the list and the description of printer and Ethernet parameters see the following paragraphs.
PRINTER NAME and
FIRMWARE RELEASE
KEYS FUNCTIONS
(see paragraph 2.4)
PRINTER STATUS
(see paragraph 5.3)
PRINTER PARAMETERS
(see paragraph 5.4)
PRINTER SETTINGS
PRINTER TYPE ...................................KPM216HII
PRINTING HEAD TYPE.......................TT3T216-4I
INTERFACE .........................................RS232
PROGRAM MEMORY TEST................OK
DYNAMIC RAM TEST..........................OK
EEPROM TEST....................................OK
CUTTER TEST.....................................OK
PRINTER HEAD Rav...........................800
HEAD VOLTAGE [V] = 24.55
HEAD TEMPERATURE [°C] = 26
PAPER PRINTED [cm] = 3590
CUT COUNTER = 35
RETRACT COUNTER = 0
POWER ON COUNTER = 70
Printer Emulation............................ : ESC/POS (TM)
RS232 Baud Rate .......................... : 115200 bps
RS232 Data Length........................ : 8 bits/chr
RS232 Parity..................................: None
RS232 Handshaking ...................... : Xon/Xoff
Busy Condition ............................... : RxFull
USB Mass Storage......................... : Disabled
USB Address Number.................... : 0
Print Mode...................................... : Normal
Autofeed......................................... : CR disabled
Chars / inch .................................... : A=11 B=15cpi
Speed / Quality...............................: Normal
Automatic Ejecting.......................... : Disabled
Paper Retracting ............................ : Disabled
Paper Width.................................... : 200 mm
Paper Threshold............................. : 30%
Notch Alignment ............................. : Enabled
Notch Threshold ............................. : 40%
Notch Distance [mm]...................... : +00.0
PaperEnd Buffer Clear................... : Disabled
Short ticket (<150mm).................... : Disabled
Print Density...................................: 0%
[LF] enter Printer Setup
[FF] enter Ethernet Setup
[LF + FF] skip Setup
KPM216HII printer
SCODE: <code> - rel 1.00
BCODE: <code> - rel 1.00
FCODE: <code> - rel 1.00
UCODE: <code> - rel 1.00
DCODE: <code> - rel 1.00
CPLD - rel 1.00
5. CONFIGURATION
User manual KPM216HII ETH 41
