7.4 Power supply dimensions cod. 964GE010000350 (optional)
Length 198 mm
Height 50 mm
Width 99 mm
49.549.5
63.0
2xM4
65.0 70.0
176.5
10.0 11.5
50.0
21.0
12.5 25.0 12.5
29.0
25.025.0
25.0 117.0 56.0
99.0
198.0
+V
+V
-V
-V
PE
N
L
7. SPECIFICATIONS
70 KPM216HII ETH User manual
