5.6 Hexadecimal dump
This function is used to diagnose the characters received through the communication port; the characters are printed
out both as hexadecimal codes and ASCII codes.
Once the self-test routine has fi nished, the printer enters Hexadecimal Dump mode. The printer remains in standby
until a key is pressed or characters are received through the communication port. For example, in the 200 dpi model,
for every 8 characters received, the hexadecimal and corresponding ASCII codes are printed out (if the characters
are underlined, the receive buffer is full). Shown below is an example of a Hexadecimal Dump:
HEXADECIMAL DUMP
50 72 69 6E 74 20 4C 69 6E 65 0A 50 72 69 Print Line·Pri
6E 74 20 4C 69 6E 65 0A 50 72 69 6E 74 20 nt Line·Print
4C 69 6E 65 0A 50 72 69 6E 74 20 4C 69 6E Line·Print Lin
65 0A 50 72 69 6E 74 20 4C 69 6E 65 0A 50 e·Print Line·P
72 69 6E 74 20 4C 69 6E 65 0A 50 72 69 6E rint Line·Prin
74 20 4C 69 6E 65 0A 50 72 69 6E 74 20 4C t Line·Print L
69 6E 65 0A 50 72 69 6E 74 20 4C 69 6E 65 ine·Print Line
0A 50 72 69 6E 74 20 4C 69 6E 65 0A 50 72 ·Print Line·Pr
5. CONFIGURATION
User manual KPM216HII ETH 47
