2.5 Status led fl ashes
The Status led indicates hardware status of device. Given in the table below are the various led signals and the cor-
responding printer status.
STATUS LED DESCRIPTION
- OFF PRINTER OFF
GREEN ON PRINTER ON: NO ERROR
GREEN
COMMUNICATION
STATUS
1 x RECEIVE DATA
2 x RECEPTION ERRORS
(PARITY, FRAME ERROR, OVERRUN ERROR)
3 x COMMAND NOT RECOGNIZED
4 x COMMAND RECEPTION TIME OUT
YELLOW
RECOVERABLE
ERROR
2 x HEADING OVER TEMPERATURE
3 x PAPER END
4 x PAPER JAM
5 x POWER SUPPLY VOLTAGE INCORRECT
6 x COVER OPEN
RED
UNRECOVERABLE
ERROR
3 x RAM ERROR
4 x EEPROM ERROR
5 x CUTTER ERROR
6 x CUTTER OPEN
2. DESCRIPTION
User manual KPM216HII ETH 13
