12.3 Embedded Web Server: access
To enter the Embedded Web Server, type the IP address assigned to the printer into Web browser. For example, if IP
address of the printer is 192.168.10.37, type in the Web browser:
http://192.168.10.37
On the screen will appear the internal default page that corresponds to the section “Device Info” The home page is
divided into 6 areas whose functions are described below:
1. SECTIONS: The web server has three sections listed within each web page. These sections are:
Device Info, Printer Settings, Printer Support.
2. CURRENT PAGE Reports section currently displayed.
3. TOOLS Lists the tools available within the chosen section.
4. PRINTER PICTURE Displays a picture representative of the printer operational status. The picture changes
depending on the parameters reported in area number 5.
5. REAL TIME STATUS Report a list of operating parameters controlled and monitored in real time (with a
regular refresh from 5 to 15sec).
6. TIME AND DATE Displays the current time and date.
Model Information
Printer Parameter
RealTime Status
Network Settings
Advanced Status
Web Site
DEVICE INFO
< Device name >
< PRINTER >
< PRINTER >
Cover Open
Cover Open
Paper End
Near Paper End
Paper rolling
Paper End
Ticket Out
LF key pressed
FF key pressed
S1 key pressed
S2 key pressed
Over temperature
Supply Voltage error
Cutter error
Cutter Open
Memories Error
Paper Jam
Notch Search...
Notch Error
'(9,&(,1)2Ň35,17(56(77,1*6Ň35,17(56833257
12:00 01-01-14
4
2
1
6
3
5
NOTE:
To know the IP address of the printer, print the Set-up report of the printer (see chapter 5) or use “Locator”.
12. ADVANCED FUNCTIONS
User manual KPM216HII ETH 97
