3.3 Fixing brackets
The printer includes a kit for the assembly of two additional fi xing brackets (see following fi gure).
The kit contains:
1. Two fi xing brackets;
2. No.4 fi xing screws.
1
1
2
For the assembly procedure, proceed as follows:
1
Remove the side cover by rotating the lock/unlock.
BUTTON IN
UNLOCKED
POSITION
BUTTON IN
LOCKED
POSITION
3. INSTALLATION
User manual KPM216HII ETH 17
