2
Fix the brackets as shown in Fig.
Observe the orientation of the slot A.
A
A
The following fi gure shows the printer overall dimensions with the two additional brackets (dimensions in mm).
269
11510 10
4 x 10 (No.4)
3. INSTALLATION
18 KPM216HII ETH User manual
