7.6 Speci cations for ticket with black mark
Printer is provided with a sensor for the notch detection as described in chapter 10.
The following gure shows an example of paper roll with black mark, where:
Dmin. = minimum notch to notch distance:
min. 150mm (if the “Short Ticket” parameter is disabled)
min. 105mm (if the “Short Ticket” parameter is enabled)
NON THERMAL SIDE
Dmin
194 ÷ 216
94
Notch
Ticket axis
Notch axis
10
5
+1
0
7. SPECIFICATIONS
72 KPM216HII ETH User manual
