4
The user withdraw the ticket from the paper mouth
3
When printing ends, the device cuts the ticket and
presents a portion of the ticket printed on the paper mouth
Paper out in vertical position
Ticket presented
Paper cut Ejector rollers
Paper out
in horizontal position
Ticket
presented
Paper out
in horizontal position
Ticket
withdrew
Paper out in
vertical position
Ticket withdrew
4. OPERATION
32 KPM216HII ETH User manual
