Custom Audio Electronics KPM216HII-ETH User Manual

V
ROOM
3
Insert the paper into the paper infeed opening and wait for it to load automatically.
Paper out in horizontal position
Paper out in vertical position
The following fi gure gives the
limit positions of the paper
roll related to the printer for a
correct paper loading without
a paper roll holder support.
The direction of the paper
will always form a maximum
angle of 20 ° or -20 ° with the
insertion plane of paper inside
the printer.
max 1°max 1°
max 1°max 1°
20°20°
20°20°
4. OPERATION
30 KPM216HII ETH User manual
