ELECTRICAL SPECIFICATIONS POWER SUPPLY cod. 964GE010000350 (OPTIONAL)
Power supply voltage from 100 Vac to 240 Vac
Frequence from 47 Hz to 63 Hz
Current (output) max. 9,6 A
Power 230W
ENVIRONMENTAL CONDITIONS
Operating temperature from 0°C to +50°C
Relative humidity from 10% Rh to 85% Rh
Storage temperature from -20 °C to +70 °C
Storage relative humidity from 10% Rh to 90% Rh
NOTES:
(1)
: Respecting the regular schedule of cleaning for the device components.
(2)
: “Veramono.ttf” and “Vera.ttf” are installed on printer fl ash disk. It is possible to install additional TrueType fonts
(see par.12.8).
(3)
: Referred to a standard CUSTOM receipt (L=10cm, Density = 12,5% dots on).
(4)
: For external rolls diameter higher to Ø100mm it’s recommended to use a paper pretensioning device.
(6)
: If the “Short Ticket” parameter is enabled (see the paragraph 5.4), it’s possible to reach the minimum length of
110 mm.
7. SPECIFICATIONS
User manual KPM216HII ETH 67
