xStack
®
DGS-3200 Series Layer 2 Gigabit Ethernet Managed Switch
94
Editing an existing ISM VLAN Group List Setting:
1. Click the Group List link next the ISM Profile you want to edit.
2. The following window opens:
Figure 3 - 32. ISM VLAN Settings window
3. Type in the Multicast address range you want to add to the ISM Profile in the Multicast Address List field.
4. Click the Add button to add the Multicast Address List to the ISM profile.
IP Multicast Profile Settings
Users can a dd a profile to which multicast address(es) reports are to be received on specified ports on the Switch. T his function
will therefore limit the number of reports received and the number of multicast groups configured on the Switch. The user may set
an IP M ulticast address or range of IP Multicast addresse s to acc ept reports (Permit) or de ny reports ( Deny) c oming i nto t he
specified switch ports.
To view the following window, click L2 Features > IGMP Snooping > IP Multicast Profile Settings:
Figure 3 - 33. IP Multicast Profile Settings window
The following fields can be set:
Parameter Description
Profile ID
Enter a Profile ID between 1 and 24.
Profile Name
Enter a name for the IP Multicast Profile. This name can be up to 32 characters in length.
To change an entry, click the corresponding Modify button in the Multicast Address List column. The Multicast Address Group
List Settings window opens. To edit the name of an entry, click th e corresponding Edit button in the Edit Profile Name column.
To remove an entry, click the corresponding Delete button.
