xStack
®
DGS-3200 Series Layer 2 Gigabit Ethernet Managed Switch
243
Browse Session Table
Users can display the management sessions since the Switch was last rebooted.
To view the following window, click Monitoring > Browse Session Table:
Figure 7 - 32. Browse Session Table window
IGMP Snooping Group
Users can view the Switch’s IGMP Snooping Group Table. IGMP Snooping allows the Switch to read the Multicast Grou p IP
address and the corresponding MAC address from IGMP packets that pass through the Switch.
To view the following window, click Monitoring > IGMP Snooping Group:
Figure 7 - 33. IGMP Snooping Group window
The user may search the IGMP Snooping Group Table by either VLAN Name or VID List by entering it in the top left hand corner
and clicking Find.
The following fields and settings can be viewed:
Parameter Description
VID List/VLAN
Name
The VID List or VLAN Name of the multicast group.
VID/VLAN Name
The VID or VLAN Name of the multicast group.
IP Address
Enter the IP address.
Delete
Click this button to delete the designated IGMP snooping groups learned by the Data Driven
feature.
Delete All
Click this button to delete all the IGMP snooping groups learned by the Data Driven feature.
NOTE: To configure IGMP snooping for the Switch, go to the L2 Features folder and
select IGMP Snooping > IGMP Snooping Settings.
