xStack
®
DGS-3200 Series Layer 2 Gigabit Ethernet Managed Switch
1
Section 1
Web-based Switch Configuration
Introduction
Logging onto the Web Manager
Web-Based User Interface
Introduction
All software functions of the Switch can be managed, configured, and monitored via the embedded web-based (HTML) interface.
Manage the Switch from remote stations anywhere on the network through a standard browser, such as Internet Explorer 5.5 or
later, Net scape 8. 0 or l ater, Fi refox 2.0 or l ater, o r Apple Sa fari 3.0. The b rowser act s as a u niversal a ccess t ool a nd ca n
communicate directly with the Switch using the HTTP protocol.
The Web-based m anagement m odule a nd the Console program (and T elnet) a re different ways t o access t he sa me interna l
switching software and configure it. Th us, all settings encountered in web-based management are t he same as t hose found in the
console program.
Logging onto the Web Manager
To begin managing the Switch, simply run the browser installed on your computer and point it to the IP address you have defined
for the device. The URL in the address bar should read something like: http://123.123.123.123, where the numbers 123 represent
the IP address of the Switch.
NOTE: The factory default IP address is 10.90.90.90.
This opens the management module's user authentication window, as seen below.
Figure 1- 1. Enter Network Password window
Enter “admin” in both the User Name field and t he Password field and click OK. This will ope n the Web-based user interface.
The Switch management features available in the web-based manager are explained below.
