xStack
®
DGS-3200 Series Layer 2 Gigabit Ethernet Managed Switch
Upload Log File/Upload Log File to TFTP
A history and attack log can be uploaded from the Switch to a TFTP server.
Open the Tools drop-down menu on the left-hand side of the menu bar at the top of the Web manager and click Upload Log File
to open the following window:
Figure 8 - 14. Upload Log File window (DGS-3200-10 and DGS-3200-16)
Figure 8 - 15. Upload Log File to TFTP window (DGS-3200-24)
To upload a log file, e nter a TFTP Server IP address and TFTP File/path name. Select either IPv4 or IPv6 and then click Upload
or Upload Attack Log.
Reset
The Reset function has several options when resetting the Switch. So me of the current configuration parameters can b e retained
while resetting all o ther configuration parameters to th eir factory defaults. Reset g ives the option of retaining the Switch's User
Accounts and History Log, while resetting all other configuration parameters to their factory defaults. If the Switch is reset using
this window, an d neither Save Confi guration nor Save Al l is ex ecuted, th e Switch will return to t he last saved configuration
when rebooted.
Open the Tools drop-down menu on the left-hand side of the menu bar at the top of the Web manager and click Reset to open the
following window:
Figure 8 - 16. Reset System window
NOTE: Only the Reset System option will enter the factory default parameters into the Switch's
non-volatile RAM, and then restart the Switch. All other options enter the factory default values
into the current configuration, but do not save this configuration. Reset System will return the
Switch's configuration to the state it was when it left the factory.
255
