xStack
®
DGS-3200 Series Layer 2 Gigabit Ethernet Managed Switch
130
MAC Block List
This table is used to view unauthorized devices that have been blocked by IP-MAC binding restrictions. To find an unauthorized
device M AC address t hat h as bee n blocked by t he I P-MAC bi nding rest rictions, e nter t he V ID and M AC Address i n t he
appropriate fields and click Find. To view all entries, click the View All button. To delete an entry, click the Delete button next to
the entry’s port. To delete all the entries in this window, click the Delete All button.
To view this window, click Security > IP-MAC-Port Binding (IMPB) > MAC Block List, as shown below:
Figure 5 - 10. MAC Block List window
The following fields can be set or modified:
Parameter Description
VID
Enter the VLAN ID number of the VLAN you want to find or delete.
MAC Address
Enter the MAC address of the MAC Address you want to find or delete.
