(1) Safety Chain
H11O104A
H11O682A
DRAW BAR AND TRAILER
The drawbar is used to pull an imple-
ment, such as a trailer. Make sure to
check the max. towing weight of the
trailer and max. vertical load that can
be applied to the drawbar.
(1) Drawbar
T22O602A
Type Drawbar
Approval number To be announced
Maker Daedong or Kioti
Maximum horizontal load/D-Value : N/A
Towable mass (T) :
12,676 ~ 13,448 lb.
(5,750 ~ 6,100 kg)
Maximum permissible vertical load on the coupling point :
7,275 lb. (3,300 kg)
Position of cou
-
pling point
Height above ground
13.3 in. (338 mm)
Distance from vertical plane passing
through the axis of the rear axle
24.6 in. (626 mm)
