CK2610CHSE / CK3510(H,C,CH)SE / CK4010(H,C,CH)SE
1. The hood opener is a rod placed in
the frame hole to ensure safety.
To open the hood, press in the
opener with the ignition key or ap-
propriate tool.
2. The hood stays open by itself with
air cylinder. To close it, just press
down without any bothering pro-
cess.
td2O702A
MAINTENANCE CODE
HOW TO DISCONNECT THE HOOD (A)
(1) Hood (2) Opening Button
(A) Press (B) Open
(1) Hood
Never open the hood while the
engine is running.
•
CAUTION
tC2O701A
(1) Fuel Tank Cap
CHECKING AND ADDING FUEL (C)
The fuel tank is installed in the mid-
dle of the tractor body. Make sure to
use pure and high-quality diesel fuel.
FUEL TANK CAPACITY
8.98 U.S.gal. (34 L)
A
11
A
22
BB
tC2O752A
