CK2610CHSE / CK3510(H,C,CH)SE / CK4010(H,C,CH)SE
JOYSTICK VALVE
(A) A2 : Bucket Up (Roll Back)
(B) B2 : Bucket Down (Dump)
(C) A1 : Boom Up
(D) B1 : Boom Down
Te1O621A
To avoid accidents:
Pressurized diesel fuel or hy-
draulic fluid may be sprayed
on your skin or eyes, lead-
ing to a severe injury or even
death.
To ch e ck fo r l e aks , u s e a
board and wear protective
gloves and goggles.
If your eyes come into contact
with the hydraulic fluid, see
your doctor immediately.
Never try to disconnect the
tube and quick coupler while
the tractor and implement are
in operation. Release the pres-
sure by operating the lever
after the engine is stopped.
•
•
•
•
WARNING
The hoses and couplers for in-
stallation are supplied with the
implements (like front loader).
•
NOTE
