CK2610CHSE / CK3510(H,C,CH)SE / CK4010(H,C,CH)SE
DPF REGENERATION UNDERWAY LAMP (CK3510/CK4010 ONLY)
DPF REGENERATION WARNING LAMP
tC2O432C tC2O434C
1. Stage 1 warning lamp for DPF
clogging
: DPF Soot Loading Level 120% -
160%
Manual regeneration required.
Engine RPM limit is activated
(below 2,200 rpm)
If the DPF is not regenerated in the
stage 1 warning state, the warning
lamp blinks. In this state, make sure
to perform DPF regeneration pro-
cess. (see page 4-11)
Do not touch or come near the
DPF part during the regenera-
tion process as its surround-
ing area is hot. If not, you can
get burnt.
•
WARNING
This lamp comes on while the regen-
eration process is being performed in
the DPF.
If the DPF regeneration under-
way lamp is illuminated during
operation, please keep the en-
gine rpm at 1,500 or above.
•
IMPORTANT
