CK2610CHSE / CK3510(H,C,CH)SE / CK4010(H,C,CH)SE
PARKING BRAKE WARNING
LAMP
PREHEAT INDICATOR
When the parking brake is applied,
the lamp comes on.
If this indicator is ON even
with the park ing brak e re -
l e a s e d , h a v e t h e t r a c t o r
checked by your local dealer
or workshop immediately.
•
CAUTION
This indicates the operating condition
of the preheat system. This indica-
tor comes on for approx. 8 seconds
when the key switch is turned to the
“ON” position. In case of the basic
model, this indicator comes on when
the key is held in the “PRE-HEAT”
position by an operator.
tC2O427C
tC2O428b
tC2O491a
The lamp comes on when the syn-
chronization switch or lever is con-
nected.
LINKED PEDAL LAMP (IF
EQUIPPED)
