TACHOMETER/HOURMETER PTO SPEED FUEL GAUGE
(1) Tachometer (2) Hourmeter
The tachometer indicates the engine
rpm.
The hour meter indicates the total
run hours of the tractor in 6 digits.
The last digit represents 1 hour.
The hourmeter does not operate if
the engine is stopped even if the key
switch is in the "ON" position.
(1) 540 rpm
It indicates the engine rpm that can
drive 540 rpm of the PTO speed. For
speedy and effective work, adjust the
work load so that the engine rpm is
close to this mark "
540
".
(1) Fuel Gauge
E: Empty F: Full
This gauge indicates the remain-
ing fuel level after the key switch is
turned to the “ON” position.
•
F
: Fuel is fully lled.
•
E: Replenish the fuel tank.
If driving is continued with the nee
-
dle below the position “E,” air may
enter the fuel supply system. In this
case, “bleed” the system. (For de-
tailed instructions, refer to “Bleeding
fuel system” in the chapter “Mainte-
nance”)
tC2O418btC2O416C tC2O417d
