PROPER BRAKE PEDAL FREE
TRAVEL (A)
0.8 ~ 1.2 in. (20 - 30 mm)
Stop the engine and chock the
wheels before checking brake
pedal.
Keep the free play in the right
and left brake pedals equal.
•
•
CAUTION
3. When adjustments are needed,
loosen the locking nut and turn the
turn buckle until the rod length is
at the desired and acceptable limit.
4. After adjustment, tighten the lock-
ing nut rmly.
5. Repeat the same procedure for the
left brake pedal and measure its
free play.
6. Interlock the brake pedals after
checking or adjusting them.
To Next Page
