CK2610CHSE / CK3510(H,C,CH)SE / CK4010(H,C,CH)SE
H11O655A
3. If the fuse is blown, replace it with
a new fuse with same capacity.
Make sure it is rmly installed.
4. Install the fuse box cover.
5A
20A
10A
Start
5A
25A
Cluster
Cluster_(B)
10A
PTO
10A
Alternator
Brake_Lamp Fuel_Heater
5A
ECU_Control
20A
ECU_Main
25A
A/C Power
Work_Lamp
Deffoger
20A
Head_Lamp
Tail_Lamp
15A
Flasher
Horn
Beacon Lamp
(Option)
Power_Outlet
Spare
25A
10A
25A
Wiper
15A
Stereo
10A
Beacon_Lamp
(Option)
20A
15A
10A
5A
Spare
Spare
Fuse
Puller
Spare
Head Lamp
ECU
Brake
PTO
Cruise
Cruise
A/C
t22O701A
CABIN
