7-0
KICK STARTER/CONTINUOUSLY VARIABLE TRANSMISSION
MOVABLEDRIVENFACE
GUIDEPIN
DRIVENFACE
RAMPPLATE
WEIGHTROLLER
MOVABLEDRIVEFACE
DRIVEFACEBOSS
DRIVEFACE
KICKSTARTERSPINDLE
KICKDRIVENGEAR
KICKSTARTERRETURNSPRING
KICKSPINDLEBUSH
DRIVEBELT
MOVABLEDRIVEN
FACESPRING
SHOESPRING
CLUTCHSHOE
DRIVEPLATE
CLUTCHOUTER
