DAELIM S-FIVE Service Manual

6-3
ENGINE REMOVAL/INSTALLATION
U NUT
ENGINE
HANGER LINK
● Check the following after the engine is assembled.
-Electric systems.
-Adjust of the rear brake free play.
-Inspection of the throttle cable operation.
-Inspection of the oil pump cable operation.
ENGINE HANGER LINK REMOVAL
● Remove the luggage box. (⇨3-3 )
● Remove the center cover. (⇨3-3 )
● Loosen the frame U-nut.
● Remove the frame flange bolt.
● Remove the engine hanger link.
● Install in the reverse order of removal.

DAELIM S-FIVE Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Tires (Front)	120/70-12
Tires (Rear)	130/70-12
Engine Type	4-Stroke, Air-Cooled
Transmission	Automatic
Fuel Capacity	5.5 liters
