DAELIM S-FIVE Service Manual

TRANSMISSION
DISASSEMBLY
● Remove the L. side cover. ( 7-2 )
● Remove the continuously variable transmission.
(
SECTION 7 )
● Remove the exhaust muffler. (
3-7 )
● Remove the rear wheel. (
11-3)
● Install the oil sump under the cover of transmission.
● Loosen the 6 transmission cover flange bolts.
● Remove the transmission cover.
● Remove the mission cover guide ruber.
● Remove the drive shaft from the transmission cover by
using a hydraulic press.
NOTE
·Take precautions not to damage the cover joints.
● Remove the oil seal of the drive shaft.
● Remove the final shaft gear.
● Remove the thrust washer.
● Remove the countershaft.
● Remove the counter shaft gear.
● Remove the side washer.
INSPECTION
● Inspect the drive shaft for wear or damage.
9-2
TRANSMISSION/CRANKSHAFT/CRANKCASE

DAELIM S-FIVE Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Tires (Front)	120/70-12
Tires (Rear)	130/70-12
Engine Type	4-Stroke, Air-Cooled
Transmission	Automatic
Fuel Capacity	5.5 liters
