DAELIM S2 250

10-4
CYLINDER HEAD / VALVE
● Measure the I.D. of each valve rocket arm.
SERVICE LIMITS:
IN : 10.10mm replace if over
EX: 10.10mm replace if over
● Measure each rocker arm shaft O.D.
SERVICE LIMITS:
IN : 9.90mm replace if below
EX: 9.90mm replace if below
CYLINDER HEAD
REMOVAL
● First drain the coolant from the radiator and water
jacket, then remove the thermostat water hose.
● Remove the camshaft.
● Remove the carburetor and intake manifold.
● Loosen the bolt securing the thermostat housing and
the thermostat housing.
● Remove the cylinder head.
● Remove the dowel pins and cylinder head gasket.
● Remove the cam chain guide.
● Remove all gasket material from the cylinder head
mating surface.
·If the valve rocker arm contact surface is worn,
check each cam lobe for wear or damage.
CAMSHAFT HOLDER INSPECTION
● Inspect the camshaft holder, valve rocket arms and
rocker arm shafts for wear or damage.
