Dahua DH-XVR1B08 User Manual

Local Configurations 127
5.6.1.6 Exporting IP Address
You can export the added IP address to the USB storage device.
The exported information is saved in .csv file, which includes IP address, port number, channel
number, manufacturer, user name, and password.
Insert the USB storage device to the USB port of the Device. Step 1
Click Export. Step 2
The Browse interface is displayed. See Figure 5-89.
Figure 5-89
Configure the save path. Step 3
Click OK to save the settings. Step 4
A pop-up message indicating "Successfully exported" is displayed.
Click OK. Step 5
When exporting IP address, the File Backup Encryption check box is selected by default. The
file information includes IP address, port, channel number, manufacturer, user name, and
password.
 If you select the File Backup Encryption check box, the file format is .backup.
 If you clear the File Backup Encryption check box, the file format is .csv. In this case,
there might be a risk of data leakage.
5.6.1.7 Importing IP Address
You can add remote devices by importing IP address information.
Insert the USB storage device to the USB port of the Device. Step 1
Click Import. Step 2
The Browse interface is displayed. See Figure 5-90.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
